For big commercial farm
2F-30 Fertilizer spreaders adapt to all kinds of work: spreading fertilizer across open fields, along field edges and marginal zones, late fertilization, and application to special crops etc. have working widths of 10 to 42 meters, distribute all kinds of products: mineral or organic fertilizer, gravel, salt, lime, etc.
Attachment to tractor | 3 Point suspension II/Ⅲ |
PTO Speed | 450r/min 650r/max |
Working width | between 12 and 42m |
Hopper size | 240*130 cm |
Max. capacity | 3000 L |
Total weight | 320 Kgs |
Working width adjustment | Per half-width |
No. of Diffusers Blade | 2 |
Overall Demension | 2400*1300*1010 mm |
For small and medium size farm
2FS Series Fertilizer spreaders The main supporting parts transmission gearbox, coupling, and transmission shaft purchased from famous supplier , which have low failure rate and greatly improve the stability and service life of the machine when running at high speed. A high-end fertilizer spreader that is well received by users.
Fertilizer control mechanism: The fertilizer outlets on both sides adopt synchronous adjustment technology. You only need to rotate the handwheel to control the left and right fertilizer outlets at the same time to make the fertilizer amount on both sides uniform.
Automatic fertilizer control: Dual hydraulic automatic control of fertilizer outlet switch, manual control of fertilizer outlet switch manual, hydraulic can be switched arbitrarily. It can control single-side fertilization and boundary fertilization functions.
Fertilizer plate mechanism: Users of the fertilizer plate mechanism can adjust the fertilizer spreading width according to actual needs.
Model | 2FS-1000 | 2FS-1500 | 2FS-2000 |
Capacity | 1000 Liters | 1500 Liters | 2000 Liters |
Horse Power | 80-180 Hp | 80-180 Hp | 30-180 Hp |
Working Width | between 12 and 28m | between 12 and 28m | between 12 and 28m |
Overall Demension | 1880*1500*1000mm | 1880*1500*1300mm | 2130*1750*1900mm |
Weight | 320 Kgs | 370 Kgs | 520 Kgs |
